Frigidaire Gas Stove Repair in Signal Hill SW Calgary — Ignition Switch Replacement

Case Study: A homeowner in Signal Hill, SW Calgary, contacted Calgary Appliance Fix after none of the burners on their Frigidaire gas range would ignite. The stove was getting power, the clock and display were working fine, but every burner was completely unresponsive. No clicking, no spark, nothing. That single detail — power to the unit but zero ignition response across all burners — pointed our technician in one clear direction before even opening the appliance.

The Symptom: All Burners Not Working on a Frigidaire Gas Range

When one burner fails to ignite on a gas stove, the problem is almost always isolated to that specific burner — a clogged burner port, a cracked igniter, or a loose wire at that location. But when every single burner stops working at the same time, the cause is almost always upstream of the individual burners. Something shared between all of them has failed.

On a Frigidaire gas range, the component that controls spark ignition across all burners is the Spark Ignition Switch and Wire Harness Assembly. This assembly connects the ignition switches on the control panel to each individual burner igniter. When it fails, it cuts off the ignition signal to every burner simultaneously — which is exactly what this Signal Hill homeowner was experiencing.

Diagnosis: Frigidaire Spark Ignition Switch and Wire Harness Assembly

Our technician arrived at the Signal Hill home, confirmed power was reaching the unit, and tested each burner igniter individually. Every igniter was receiving no signal. The control panel switches were tested next — no output. The fault was traced to the Frigidaire Range Spark Ignition Switch With Wire Harness Assembly, a single component that had failed and taken out ignition across the entire cooktop.

This is a common failure point on Frigidaire gas ranges, particularly on models that have been in use for several years. The wire harness can develop breaks or connection failures over time, and the ignition switches themselves wear out with regular use. When the assembly goes, the whole cooktop loses spark ignition at once.

The part was confirmed, and the homeowner was given a clear upfront quote before any work began. The repair was approved on the spot — but there was one complication: the Frigidaire Spark Ignition Switch With Wire Harness Assembly was not available through any Canadian or US supplier at the time. The part had to be ordered directly from the manufacturer, which meant the customer needed a second appointment once it arrived.

We were upfront with the homeowner about the wait, kept them informed throughout the process, and scheduled the installation as soon as the part was in hand.

The Repair: Spark Ignition Switch With Wire Harness Assembly Replacement

Replacing the Frigidaire Spark Ignition Switch With Wire Harness Assembly involves removing the cooktop panel, disconnecting the old harness from each burner igniter and the control switches, and installing the new assembly in reverse order. Every connection point is tested before the cooktop is reassembled to confirm the spark signal is reaching each burner correctly.

Once the new assembly arrived and was installed, every burner on the Frigidaire range lit immediately and consistently on the first turn of each knob. The stove was fully operational and the Signal Hill homeowner had their kitchen back.

This repair is a good reminder that some parts — particularly for specific Frigidaire gas range models — are not always available locally and may need to be sourced directly from the manufacturer. It is not the most common situation, but it does happen, and we always communicate timelines honestly so homeowners know exactly what to expect.

Why All Burners Stopped Working at the Same Time

This is the question most homeowners ask when they call us about a gas stove that won't ignite. It seems like a big failure, but it almost always comes down to one shared component rather than multiple things failing at once. On Frigidaire gas ranges, that shared component is the ignition switch and wire harness assembly.

Here is a simple way to think about it: each burner has its own igniter, but all of those igniters get their signal from the same source — the ignition switch assembly. When that source fails, every burner loses ignition at the same time. It looks like a major problem, but it is a single-part replacement.

This is exactly why it is worth calling a technician before assuming the stove needs to be replaced. A Frigidaire gas range that has lost all burner ignition is very likely repairable in a single visit.

Common Frigidaire Gas Stove Problems We Repair in Calgary

The Signal Hill ignition switch repair is one of the most common Frigidaire gas stove issues we see across Calgary and surrounding communities. Here are other Frigidaire gas range problems we regularly diagnose and fix:

• One burner not igniting — usually a cracked igniter cap, clogged burner port, or faulty individual igniter

• Burner clicking constantly but not lighting — often a wet or dirty igniter, or a failed spark module

• Oven not heating — igniter glow bar failure is the most common cause on Frigidaire gas ovens

• Oven temperature inaccurate — faulty temperature sensor or control board calibration issue

• Burner flame uneven or lifting off — burner port blockage or gas pressure issue

• Control knobs not responding — control board or switch failure

If your Frigidaire gas stove is showing any of these symptoms, the repair is almost always straightforward when caught early. Waiting typically means more wear on surrounding components and a more involved fix.

Serving Signal Hill and All of Calgary

Calgary Appliance Fix serves all of Calgary and the surrounding region, including every quadrant of the city:

• SW Calgary — Signal Hill, Springbank Hill, Aspen Woods, Evergreen, Shawnessy, Woodbine, Glamorgan, Lakeview, and surrounding neighbourhoods

• NW Calgary — Tuscany, Scenic Acres, Citadel, Hamptons, Silver Springs, and surrounding neighbourhoods

• NE Calgary — Skyview Ranch, Cornerstone, Saddle Ridge, Coventry Hills, and surrounding neighbourhoods

• SE Calgary — Auburn Bay, Mahogany, McKenzie Towne, Copperfield, and surrounding neighbourhoods

• Okotoks — All neighbourhoods throughout town

• Chestermere — Full coverage across this growing community east of Calgary

• Langdon — Rocky View County east of Calgary

• De Winton — Rural community south of Calgary along Highway 2A

• Harmony — Master-planned community near Springbank

• Priddis — Foothills community west of Calgary

• Bragg Creek — Hamlet west of Calgary near Kananaskis Country

Same-day and next-day gas stove repair is available across all of these areas. If your Frigidaire range — or any other brand of gas stove — is not igniting, call us early in the day to secure the fastest available appointment.

📞 Call 403-399-5949 | 🌐 www.calgaryappliancefix.ca | Open 24/7 for bookings

Frequently Asked Questions: Gas Stove Repair in Calgary

Why are all the burners on my gas stove not igniting?

When all burners stop igniting at the same time, the cause is almost always a shared component — on Frigidaire ranges, this is typically the spark ignition switch and wire harness assembly. It is a single-part replacement. While we carry many common parts on our trucks for single-visit repairs, specialty or manufacturer-direct parts may require a quick second follow-up visit to install.

Is it worth repairing a Frigidaire gas stove?

In most cases, yes. Gas stoves are durable appliances, and most failures involve specific components rather than the whole unit. If the repair cost is under 50 percent of the replacement value, repair is almost always the better financial choice.

How quickly can you repair a gas stove in SW Calgary?

We offer same-day and next-day gas stove repair throughout SW Calgary, including Signal Hill, Springbank Hill, Aspen Woods, and surrounding neighbourhoods. Call 403-399-5949 early in the day for the fastest available slot.

Do you repair Frigidaire appliances in Calgary?

Yes. Frigidaire is one of the most common appliance brands we service across Calgary, Okotoks, Chestermere, and surrounding areas. We carry parts for Frigidaire gas ranges, ovens, fridges, washers, and dryers.

Is a gas stove repair safe to do without a technician?

Gas appliance repairs should always be handled by a trained technician. Incorrect reassembly of gas components can create a leak or an ignition hazard. Every gas stove repair completed by Calgary Appliance Fix is done in accordance with Alberta safety standards.
